MCR-C-UI-UI-DCI/HUAD401152P0001 | Phoenix Contact Signal conditioner

MCR 3-way signal conditioner, with configurable input/output, for the electrical isolation of analog signals, preconfigured. For information on permitted signal combinations, please refer to the data sheet. Replacement item: 2811284 MACX MCR-UI-UI. The MCR-C-UI-UI(-450)-DCI(-NC) 3-way signal conditioner is used to electrically isolate and convert analog signals. It ensures the electrical isolation of standard analog signals. The module input and output are electrically isolated and supplied by the mains via integrated DC/DC converters (3-way isolation). A green power LED indicates the required auxiliary energy. Alignment span:± 2 %Alignment zero:± 2 %Electrical isolation between input and output:yesLimit frequency (3 dB):30 HzMaximum power dissipation for nominal condition:900 mWTest voltage input/output:1.5 kV AC (50 Hz, 60 s)Test voltage power supply/signal:1 kV AC (50 Hz, 60 s)Protective circuit:Transient protectionStep response (10-90%):11 msMaximum temperature coefficient:0.0075 %/KMaximum transmission error:≤ 0.1 % (of final value)
